Technical Specifications
B-2
SIMATIC Rack PC IL 40 SManual
A5E00200171-01
General
Order nos. See order documentation
Dimensions (w x h x d) 430.4x177.4x44.4 (w x h x d in mm)
For more details refer to chapter 3.2
Weight min. 16 kg, max. 23 kg
Supply voltage (U
N
) 120 V AC to 240 V AC (90 ... 264 V AC)
Line voltage frequency 50 - 60 Hz
Brief voltage interruption acc. to Namur 61 ms at 0.85 U
N
(max. 10 times per hour; min. recovery time 1 s)
max. power consumption 460 W
max. current output +3,3V/18A
+5V/20A
(in total 135W)
+12V/18A
–12V/1A
+5Vaux/2A
Noise emission < 45 dB(A) to DIN 45635
Enclosure IP 30 front, IP 20 at the rear
Safety
Protection class Protection class I acc. to IEC 60536
Safety specifications IEC 60950 acc. to DIN VDE 0805, EN 60950, UL 60950,
cULus
Electromagnetic Compatibility (EMC)
Emitted interference EN 55022 Class B, FCC Class A, EN 61000-3-2 Class D and
EN 61000-3-3
Noise immunity:
Mains borne disturbance variables on
supply lines
± 2 kV (to IEC 61000-4-4; Burst)
± 1 kV (to IEC 61000-4-5; Surge symm)
± 2 kV (to IEC 61000-4-5; Surge unsymm)
Noise immunity on signal lines ± 1 kV (to IEC 61000-4-4; Burst; length < 10m)
± 1 kV (to IEC 61000-4-5; Surge symm; length > 30m)
± 2 kV (to IEC 61000-4-5:1995; Surge unsymm;
length > 30 m)
Noise immunity to discharges of static
electricity
± 4 kV contact discharge (to IEC 61000-4-2)
± 8 kV air discharge (to IEC 61000-4-2)
Immunity to RF interference 10 V/m 80-1000 MHz, 80% AM (to IEC 61000-4-3)
10 V/m 900 MHz and 1.89 GHz, 50% ED
(to IEC 61000-4-3)
10 V 9KHz- 80MHz (to IEC 61000-4-6)
Magnetic field 30 A/m 50/60Hz (to IEC 61000-4-8)
