Technical Specifications
B-3
SIMATIC Rack PC IL 40 SManual
A5E00200171-01
Ambient Conditions
Temperature
– operation
– storage/transport
– gradient
tested to DIN EN 60068-2-2:1994,
DIN IEC 60068-2-1,DIN IEC 60068-2-14,
+ 5°C to +35°C no limitations;
+ 5°C to +40°C no CD-RW operation,
CPU to 40W power loss
- 20°C to +60°C
Max. speed of temperature change 10
o
C/h condensation not
permitted)
Relative humidity
– operation
– storage/transport
– gradient
tested to DIN IEC 60068-2-2, DIN IEC 60068-2-30,DIN IEC
60068-2-56
5% to 80% at 25°C (no condensation)
5% to 95% at 25°C (no condensation)
(Max. speed of temperature change 10
o
C/h (50
o
F/h)
condensation not permitted)
Mechanical Specifications
Vibration
– operation *
1
– storage/transport
tested to DIN IEC 60068-2-6
20 to 200 Hz: 2 m/s
2
9 to 100 Hz: 9.8 m/s
2
Shock
– operation *
2
, *
3
– storage/transport
tested to DIN IEC 60068-2-27, 1000 shocks per axis
9.8 m/s
2
, 20 ms,
250 m/s
2
, 6 ms
Special Features
Quality assurance to ISO 9001
Motherboard
Processor Design mPGA478
– Intel Pentium4 2.4GHz, 533MHz PSB
– Intel Celeron 2.0GHz, 400MHz PSB
Main memory 2 slots
maximum 2GB DDR333/266-SDRAM (2700/2100)
(memory configuration (see order documentation)
2nd Level Cache Processor internal
Pentium 4: 512 kByte, Celeron: 128kByte)
Free expansion slots 6 PCI (max 265 mm long)
1 AGP
– max. permissible current input per
AGP slot
– max. permissible current input per
PCI slot
– max. permissible power loss per
AGP/PCI slot
– max. sum of permissible power loss
(all slots)
Vccio 3.3V 8A or 1.5V 8A; Vcc 3.3V 6A or 5V 2A;
5 V 2 A or 3.3 V 2 A, 12 V 0.3 A, -12 V 0.05 A
In all (all voltages) may not exceed a total of 25 W per slot
90 W total power consumption may not be exceeded
Drives
Floppy disk drive 3.5” (1.44 MB)
Hard disk drive 3.5” EIDE, ATA100, 60 GByte
CD-ROM, CR-R/RW 5,25” EIDE, Speed: 48 (ROM) or 48x24x48 (RW)
(see order documentation for equipment)
