Technical Specifications
B-4
SIMATIC Rack PC IL 40 SManual
A5E00200171-01
Graphics
Graphics controller Integrated Intel Extreme Graphics, 2D/3D Graphics controller
256 bits, 120 Hz max. refresh rate
Graphics memory Dynamic Video memory technology
Resolutions/frequencies/colors CRT: up to 800x600 for 120 Hz / 32 bits colors
up to 1280x1024 for 100 Hz / 32 bits colors
up to 2048x1536 for 60 Hz / 16 bits colors
350 MHz RAMDAC
DualHead AGP Graphics card 4x AGP, Dual Head Matrox Millennium G450
For details see the Matrox Millennium G450 Module CD
Ports
Serial/COM1 Serial port 1, (FIFO, 16550 compatible), 25 pin subminiature
Cannon connector
Serial/COM2 (optional) Serial port 2, (FIFO, 16550 compatible), 25 pin subminiature
Cannon connector
Parallel/LPT Parallel port, 25 pin subminiature Cannon connector
(standard, EPP and ECP mode)
Connection for printer with parallel port
VGA internal
alternative AGP Dual Head
1 connection for external monitor, 15 pin subminiature
Cannon connector
2x , 15 pin subminiature Cannon connector
Keyboard PS/2 keyboard connection
Mouse PS/2 mouse connection
USB 4 channels (2 behind, optional 2 in front)
high current, high speed USB 2.0
Audio
– Mic in
– Line in
– Line out 2x0.5W / 8 Ohm
Ethernet Ethernet port (RJ45), Controller Intel 82562
Function Indicators (LEDs)
SIMATIC Rack PC IL 40 S POWER
HARDDISK
STATUS
*1 When using a hard disk in a removable rack, the device should generally be free of mechanical
disturbances.
When using a CD-RW drive, the device should generally be free of mechanical disturbances while
burning.
