Siemens SIMATIC TDC User Manual

Signal modules
5.1 SM500 signal module
SIMATIC TDC hardware
112 System Manual, 08/2017, A5E01114865-AL
Connector X3 with cable SC63
The assignment of the screw terminals at interface module SU13 corresponds to the
connector assignment of X3.
Table 5- 7 Pin assignment of X3
X3
Designation
SU13
X3
Designation
SU13
1
Digital output 1
1
26
Digital input 1
26
2 Digital output 2 2 27 Digital input 2 27
3
Digital output 3
3
28
Digital input 3
28
4
Digital output 4
4
29
Digital input 4
29
5
Digital output 5
5
30
Digital input 5
30
6
Digital output 6
6
31
Digital input 6
31
7
Digital output 7
7
32
Digital input 7
32
8
Digital output 8
8
33
Digital input 8
33
9
Ext. power supply +24V
9
34
-
34
10
External ground
10
35
External ground
35
11
Digital output 9
11
36
Digital input 9
36
12
Digital output 10
12
37
Digital input 10
37
13
Digital output 11
13
38
Digital input 11
38
14
Digital output 12
14
39
Digital input 12
39
15
Digital output 13
15
40
Digital input 13
40
16
Digital output 14
16
41
Digital input 14
41
17
Digital output 15
17
42
Digital input 15
42
18
Digital output 16
18
43
Digital input 16
43
19
Ext. power supply +24V
19
44
-
44
20
External ground
20
45
External ground
45
21 Absolute encoder 1, data D+ 21 46 Absolute encoder 2, data D+ 46
22
Absolute encoder 1, data D-
22
47
Absolute encoder 2, data D-
47
23
Absolute encoder 1, clock C+
23
48
Absolute encoder 2, clock C+
48
24
Absolute encoder 1, clock C-
24
49
Absolute encoder 2, clock C-
49
25
Ground, encoder SSI
25
50
Ground, encoder SSI
50
Connector X3 with cable SC62
Only specific signal types are available at the cable ends of SC62 which can only be used for
the matching interface modules (refer to "Connection options (Page 106)").
