Siemens SIMATIC TDC User Manual

Signal modules
5.1 SM500 signal module
SIMATIC TDC hardware
114 System Manual, 08/2017, A5E01114865-AL
Terminal assignment at cable SC62, end B
Table 5- 10 Terminal assignments of the interface modules at connector X3, SC62 cable end B
X3
Designation
SU12
SB10
SB70
SB71
11
Digital output 9
1
1/51
11/12/14
1/51
12 Digital output 10 2 2/52 21/22/24 2/52
13
Digital output 11
3
3/53
31/32/34
3/53
14
Digital output 12
4
4/54
41/42/44
4/54
15
Digital output 13
5
5/55
51/52/54
5/55
16
Digital output 14
6
6/56
61/62/64
6/56
17
Digital output 15
7
7/57
71/72/74
7/57
18
Digital output 16
8
8/58
81/82/84
8/58
19
Ext. power supply +24V
9
1P
1P
1P
20
External ground
10
1M
1M
1M
Terminal assignment at cable SC62, end C
Table 5- 11 Terminal assignments of the interface modules at connector X3, SC62 cable end C
X3
Designation
SU12
SB10
SB60
SB61
26
Digital input 1
1
1/51
14/12/11
1/11/51
27
Digital input 2
2
2/52
24/22/21
2/12/52
28
Digital input 3
3
3/53
34/32/31
3/13/53
29
Digital input 4
4
4/54
44/42/41
4/14/54
30
Digital input 5
5
5/55
54/52/51
5/15/55
31
Digital input 6
6
6/56
64/62/61
6/16/56
32
Digital input 7
7
7/57
74/72/71
7/17/57
33
Digital input 8
8
8/58
84/82/81
8/18/58
34
-
9
1P
1P
1P
35
External ground
10
1M
1M
1M
