Rack
3.1 Rack UR6021 (6DD1682-0CH3)
SIMATIC TDC hardware
52 System Manual, 08/2017, A5E01114865-AL
Output voltages of the power supply
Rated output voltage
Output current
Total
for the modules
+5 V
120 A
79 A
+3.3 V
60 A
36 A
+12 V 17 A 5 A
-12 V
17 A
5 A
Note
Make sure that you do not exceed a total of 600 W (continuous load at 60 °C). This must be
ensured i your configuration.
The output currents of the individual modules are listed in the respective description.
All outputs are sustained short circuit-proof and
do not
need a basic load.
Battery
Current load Approx. 20 µA for the monitoring and
max. 180 µA for the slots 1-21
Relay contacts (X1)
Rated voltage (AC)
230 V (max. 264 V)
Rated current
2 A
NOTICE
Assignment of the contacts
Contacts consisting of combinations of safety extra-low voltage and hazardous voltages are
not permitted.
Dimensions
Number of rack slots
21
Dimensions W x H x D [mm]
approx. 482.6 x 354.9 x 343
Weight
Approx. 20 kg
