Service and maintenance
8.3 Lubrication of the XLplus and VLplus heavy-duty bearing systems
BA 2030 (2KJ4)
74 Operating Instructions, 07/2020, A5E50009094A/RS-AL
The grease quantities listed in the table are guide values.
Table 8- 7 Grease quantity [g] for relubrication
Regreasing interval
After several years without operation
Maintenance of the output-side bearing
Change the grease filling of the roller
bearing when you change the gear oil.
For refilling, use the recommended roller bearing grease.
Procedure
1. Dismantle the output-side bearing unit.
2. Clean the bearing.
3. Fill the bearing with the new grease up to approximately 30% of the free bearing chamber.
4. Reassemble the bearing unit.
Maintenance interval after regreasing
After regreasing, the maintenance interval can be increased to the following operating hours.
Table 8- 8 Maintenance interval in operating hours [h] for relubrication
Output speed n
2
