6 Commissioning the Router Kit WLAN / LAN
6.5 Configuring the SCALANCE W774-1
Application example for SIMOTICS CONNECT 400 - Router KitInbetriebnahme- und Montagehandbuch 77
6.5 Configuring the SCALANCE W774-1
6.5.1 Logging in to the Web-based Management Tool
Procedure
112. Commission the device.
113. To log in to the Web-based Management Tool, enter the IP address of the WLAN
module (192.168.1.20) in the browser.
114. Log in with the following entries:
– Name: admin
– Password: admin
Figure 6-21 Password input
You are prompted to change the default password.
