Siemens SIMOTICS CONNECT 400 User Manual

10.3 Technical data
General information
Brand name of the product SIMOTICS CONNECT 400
Product category Sensor and communication device
Product description SIMOTICS CONNECT 400 with integrated sensors monitors the condition of the
motor to provide information about motor operation and to enable optimization of
the application and process.
SIMOTICS CONNECT 400 can only be used in combination with the "SIDRIVE IQ Fleet"
MindSphere application.
Monitoring application Data analyses, based on the digital twin of the motor, and the visualization of the
motor condition are o󹪜ered comprehensively in the SIDRIVE IQ Fleet MindSphere
application.
Measured motor parameters Temperature, radial/tangential/axial vibration, electrical stator frequency, slip fre‐
quency
Calculated motor parameters Motor status (on/o󹪜), speed, torque*, electrical energy*, energy consumption*,
number of motor starts, operating hours
* currently not available in converter operation (VSD)
Other motor parameters Maintenance demanded, e.g. regreasing interval
Supported motors Three-phase, rib-cooled low-voltage asynchronous motors in line operation (DOL)
and in converter operation (VSD),
IEC shaft heights 80 to 450 and NEMA shaft heights 48 to 680
Type of installation / mounting
Type of mounting and position Mounted outside using a (glued) mounting bracket* on the cooling ribs of the
motor.
* As described in the installation instructions.
Quali󹪝ed adhesives Henkel LOCTITE® HY 4090™, Weicon Fast Metal Minute Adhesive, 3MScotch-
WeldDP8407NS
Power supply
Type of power supply

Battery pack included
Li/SOCl
2,
3.6 V, 4 cells, size AA, non-rechargeable
Life of the battery Operating time up to 2 years*, replaceable to prolong the life
* At an ambient temperature of 0° C to 40° C and with a measurement interval of 5 minutes and transmission of the stored data once every
24 hours
Memory
Internal 󹪞ash memory Data storage for at least 48 hours* if the MindSphere connection is interrupted
* At a measuring interval of 1 minute
Communication
Bluetooth ® SPBTLE-RF Bluetooth module for communication with a mobile device for commis‐
sioning and con󹪝guring the connectivity module
Compliant with Bluetooth ® V4.1
Frequency: 2402 GHz – 2480 GHz
RF output power: 2402 – 2480 MHz: 4.20 dBm (Max. e.i.r.p.)
Range: up to 10 m
* Commissioning comprises the integration into the local Wi-Fi network and onboarding to MindSphere.
Further information
10.3Technical data
SIMOTICS CONNECT 400
206 Operating Instructions, 04/2023, A5E50161952B AL
