10.5 External fan
1) External fan 3) External fan with sound absorber
2) External fan with filter 4) External fan with sound absorber and filter
Image 10-2 External fan 1GG5 with two external fan motors (A)
Table 10-2 Spare parts external fan 1GG5
No. Designation No. Designation
32.10 Housing 34.31 External grille cover
32.15 Seal 34.32 Filter mat
32.30 Louvered cover 34.33 Inside basket
Spare Parts
10.5 External fan
SIMOTICS DC 1GG5
106 Operating Instructions 02/2016
