No. Designation No. Designation
32.31 Spacer sleeves 34.35 Cover
32.50 Fan motor 34.36 Stud bolts (A)
32.51 Adapter flange 34.60 Sound-absorption cover
32.53 Fan impeller 34.62 Sound-absorption elements
34.30 Basket filter cartridge, complete 34.63 Border
10.6 Rolling-contact bearing
10.6.1 Rolling-contact bearing for 1G.5, 1H.5, shaft heights 500 to 630, drive end
Image 10-3 Rolling-contact bearing for 1G.5, 1H.5, shaft heights 500 to 630
Table 10-3 Spare parts rolling-contact bearing for 1G.5, 1H.5, shaft heights 500 to 630
No. Designation
4.00 Rolling-contact bearing bush (floating bearing)
5.00 End shield, drive end
Spare Parts
10.6 Rolling-contact bearing
SIMOTICS DC 1GG5
Operating Instructions 02/2016 107
