9.2.1 Prepare servicing work
The drawings and parts lists do not contain any detailed information about the type and
dimensions of fixing elements and components. For this reason, you should establish this
information when dismantling them and make a note of it for the purpose of reassembly.
Document the type, dimensions and arrangement of the parts so that you will be able to
reassemble the machine to its original state.
Use suitable tools to disassemble the machine.
Take measures to prevent parts from dropping down before you dismantle them, e.g. by
replacing fastening elements with extra-long screws, threaded bolts or similar. This ensures
that the part is supported after it is pulled off.
The centerings in the shaft extensions have reset threads. Use lifting gear which is suitable
for the rotor weight and direction of loading.
WARNING
Rotor can fall down
Eyebolts in accordance with DIN 580 are unsuitable for suspending the rotor. The rotor can
fall off. This can result in death, serious injury or material damage.
Use lifting gear which is suitable for the rotor weight and direction of loading.
WARNING
Machine damage caused by improper repair work
Improper servicing work can damage the machine. This can cause damages and/or faults
which can result in eventual or immediate death, serious injury, or property damage.
Properly assemble or disassemble the machine.
Use only suitable tools and equipment.
Immediately replace damaged components.
Contact the Service Center (Page 117), if necessary.
WARNING
Rotor can fall out
If the motor is in a vertical position, the rotor can fall out while work is being performed on the
locating bearing. This can result in death, serious injury or damage.
Support or unload the rotor when carrying out work with the machine in a vertical position.
Maintenance
9.2 Repair
SIMOTICS DC 1GG5
Operating Instructions 02/2016 93
