Siemens SIMOTICS DC 1GG5 User Manual

10.8.1.3 Speed sensor for construction type IM B5
Image 10-10 Speed sensor for construction type IM B5 for shaft heights 180 to 630
Table 10-10 Spare parts speed sensor for construction type IM B5 for shaft heights 180 to 630
No. Designation
55.10. Speed sensor
55.20 Bearing covers for speed sensor mounting
55.35 Tolerance ring
55.42.1 Coupling halves at speed-sensor end for cylindrical speed-sensor shaft
55.42.5 Locking screw
55.44 Coupling star
See also
Speed sensor for construction type IM B5 (Page 100)
Spare Parts
10.8 Speed sensor
SIMOTICS DC 1GG5
114 Operating Instructions 02/2016
