10.8 Speed sensor
10.8.1 Shaft heights 180 to 630
10.8.1.1 Speed sensor with conical hub
Image 10-8 Speed sensor with conical hub for shaft heights 180 to 630
Table 10-8 Spare parts speed sensor with conical hub for shaft heights 180 to 630
No. Designation
55.10 Speed sensor
55.10.1 Speed-sensor rotor
55.10.5 Fastening screw
55.10.8 Carbon brushes
55.20 Bearing covers for speed sensor mounting
55.30 Threaded shaft journal with taper
55.38 V ring
See also
Speed sensor with conical hub (Page 97)
Spare Parts
10.8 Speed sensor
SIMOTICS DC 1GG5
112 Operating Instructions 02/2016
