10.7.7 Rolling-contact bearing for 1G.6, 1H.6, shaft heights 180 to 200 with regreasing
device, drive end
Standard bearing Reinforced bearing
Table 10-10 Spare parts rolling-contact bearing for 1G.6, 1H.6, shaft heights 180 to 200 with regreasing
device
No. Designation No. Designation
4.10 Shaft sealing ring 4.47 Plain washer
4.40 Cylindrical-roller bearing (floating bear‐
ing)
4.63 Inner bearing cover with felt rings with
shorter centering recess for floating
bearing
4.41.1 Deep-groove ball bearing (floating bear‐
ing)
4.80 Grease nipple
4.46 Spring lock washer
Spare Parts
10.7 Rolling-contact bearing
SIMOTICS DC 1GG6
118 Operating Instructions 02/2016
