10.7.9 Rolling-contact bearing for 1G.6, 1H.6, shaft heights 225 to 280 with regreasing
device, drive end
Standard bearing Reinforced bearing
Table 10-12 Spare parts rolling-contact bearing for 1G.6, 1H.6, shaft heights 225 to 280 with regreasing
device
No. Designation
4.10 V ring
4.20 Outer bearing cover
4.23 Outer bearing cover with shorter centering recess for floating bearing
4.35 Grease slinger
4.40 Cylindrical-roller bearing (floating bearing)
4.41.1 Deep-groove ball bearing (floating bearing)
4.45 Compression spring
4.60 Inner bearing cover with felt rings
4.63 Inner bearing cover
4.80 Grease nipple
Spare Parts
10.7 Rolling-contact bearing
SIMOTICS DC 1GG6
120 Operating Instructions 02/2016
