10.7.10 Rolling-contact bearing for 1G.6, 1H.6, shaft heights 225 to 280 with regreasing
device, non-drive end
Locating bearing with one shaft extension Locating bearing with two shaft extensions
Table 10-13 Spare parts rolling-contact bearing for 1G.6, 1H.6, shaft heights 225 to 280 with regreasing
device
No. Designation
3.10 V ring
3.20 Outer bearing cover
3.21 Outer bearing cover (end cover)
3.30 Locking ring
3.35 Grease slinger
3.40.1 Deep-groove ball bearing (locating bearing)
3.60 Inner bearing cover with felt rings
3.80 Grease nipple
Spare Parts
10.7 Rolling-contact bearing
SIMOTICS DC 1GG6
Operating Instructions 02/2016 121
