Table 7-1 Minimum radial forces
Type 1G.6 16. 1G.6
1H.6 18.
1G.6
1H.6 20.
1G.6
1H.6 22.
1G.6
1H.6 25.
1G.6
1H.6 28.
1G.7
1H.7 35.
1G.7
1H.7 401
... 1H.
7 403
1G.7
1H.7 404
...
1H.7 405
1G.7
1H.7 45.
NU2 1.2 kN 4 kN 4.5 kN 6 kN 7.5 kN 9 kN 11 kN 14.5 kN 16.5 kN 14.5 kN
NU3 - 6 kN 7 kN 9 kN 10.5 kN 12.5 kN - - - -
7.5 Commissioning an external fan
Machines of shaft heights 250 and 280 are shipped with the air-outlet grille of the external fan
motor for connection to a 50 Hz supply already fitted. The cover sheet ① for motors which
operate on 60 Hz is supplied as a motor accessory.
NOTICE
Operation on 60 Hz
In operation on a 60 Hz supply, the external fan motor can overheat or burn out. If you intend
to operate the external fan on a 60 Hz mains supply, then fit the cover sheet ① with the
screws provided under the air-outlet grille before you commission the motor.
Commissioning
7.5 Commissioning an external fan
SIMOTICS DC 1GG6
66 Operating Instructions 02/2016
