10.7.8 Rolling-contact bearing for 1G.6, 1H.6, shaft heights 180 to 200 with regreasing
device, non-drive end
Locating bearing with one shaft extension Locating bearing with two shaft extensions
Table 10-11 Spare parts rolling-contact bearing for 1G.6, 1H.6, shaft heights 180 to 200 with regreasing
device
No. Designation No. Designation
3.10 Shaft sealing ring 3.40.1 Deep-groove ball bearing (locating
bearing)
3.20 Outer bearing cover 3.60 Inner bearing cover with felt rings
3.21 Outer bearing cover (end cover) 3.80 Grease nipple
3.30 Locking ring
Spare Parts
10.7 Rolling-contact bearing
SIMOTICS DC 1GG6
Operating Instructions 02/2016 119
