Mechanical mounting
6.1 Safety instructions
SIMOTICS M-1FE2 built-in motors
88 Hardware Installation Manual, 04/2020, A5E50074509B AA
Identification of dangers using warning and prohibition signs:
Table 6- 1 Warning signs according to ISO 7010 and their meaning
Warning - magnetic
field
(W006)
Warning - hand injuries
(W024)
Warning for electrical
voltage
(W012)
Warning - hot surface
(W017)
Table 6- 2 Prohibition signs according to ISO 7010 and their meaning
No access for persons
with pacemakers or
defibrillator implants
(P007)
No access for persons
with metal implants
(P014)
No metal objects or
watches
(P008)
Danger to life from electromagnetic fields
Electromagnetic fields (EMF) are generated by the operation of electrical power equipment
such as transformers, converters or motors.
People with pacemakers or implants are at a special risk in the immediate vicinity of these
devices/systems.
• Ensure that the persons involved are the necessary distance away (minimum 2 m).
Danger to life from permanent magnet fields
Even when switched off, electric motors with permanent magnets represent a potential risk
for persons with heart pacemakers or implants if they are close to converters/motors.
• If you have a heart pacemaker or implant, maintain a minimum distance of 50 cm.
• When transporting or storing permanent magnet motors always use the original packing
materials with the warning labels attached.
• Clearly mark the storage locations with the appropriate warning labels.
• IATA regulations must be observed when transported by air.
