Connection
7.2 Electrical connection
SIMOTICS M-1FE2 built-in motors
140 Hardware Installation Manual, 04/2020, A5E50074509B AA
7.2.3 Electrical equipment
The following equipment is provided by the spindle manufacturer:
● Terminal box or plugs, variant with at least IP54 degree of protection
● Flexible tube
● Ground cable with cable lug
7.2.4 Notes on electrical connection
The following chapter provides instructions for the electrical connection of the motor.
Responsibility of the spindle manufacturer
The spindle manufacturer installs the following cable connections:
● Power connection
● Internal protective ground cable (protection from dangerous shock currents)
● Connection of Pt1000 temperature sensors
● Encoder connection
Notes on connecting up the motor
In the standard version, the stator core has the following connection cables:
● Power connection with identification
● 2 cables for the temperature sensor (of which 1 is a spare), two-conductor, each cable
cross-section is 0.22 mm², with color coding, diameter 3 ... 4 mm
Note
Electrical connection via terminal box or power connector
The power
cables of the motor are not suitable as direct electrical interface of the spindle.
t be electrically connected via a terminal box or power connector.
● Route out the free cable ends from the spindle box in a suitable protective tubing with
cable gland to a terminal box provided by the customer.
● Ensure effective strain relief. Comply with the specified bending radii (minimum, 3 to 4x
the outer cable diameter).
