Siemens SIMOTICS Series Hardware Installation Manual

Motor components, characteristics and options
4.2 Cooling
SIMOTICS M-1FE2 built-in motors
Hardware Installation Manual, 04/2020, A5E50074509B AA
67
Cooling system manufacturers
BKW Kälte-Wärme-Versorgungstechnik GmbH
http://www.bkw-kuema.de
DELTATHERM Hirmer GmbH
http://www.deltatherm.de
Glen Dimplex Deutschland GmbH
http://www.riedel-cooling.com
Helmut Schimpke und Team Industriekühlanlagen
GmbH + Co. KG
http
://www.schimpke.org
Hydac System GmbH
http://www.hydac.com
Hyfra Industriekühlanlagen GmbH
http://www.h
yfra.de
KKT Kraus Kälte- und Klimatechnik GmbH
http://www.kkt-kraus.de
Pfannenberg GmbH
http://www.pfannenberg.com
Rittal GmbH & Co. KG
http://www.rittal.de
Note
Other manufacturers
It goes without saying that equivalent products from other manufacturers may be used. Our
recommendations are to be seen as helpful information, not as requirements or regulations.
We cannot accept any liability for t
he quality and properties/features of third-party products.
4.2.3 Configuring the cooling circuit
Note
Observing the maximum permitted pressure
The maximum permitted pressure in the cooling circuit is 0.7
MPa (7 bar).
If a
pump is deployed that produces a higher pressure, the produced pressure must be
limited by the plant with suitable measures (safety valve p
≤ 0.7 MPa, pressure control) to
the maximum permitted pressure.
● Specify the working pressure depending on the flow conditions in the supply and return of
the cooling circuit.
Select the smallest possible pressure difference between the supply and return so that
pumps with a flat characteristic curve can be used.
● Set the required coolant flow rate per time unit according to the technical data of the
equipment and motors.
Note
Install a backflush filter in the cooling circuit to prevent blockage and corrosion so that any
deposited material is flushed out.
