Siemens SIMOTICS Series Hardware Installation Manual

Motor components, characteristics and options
4.3 Encoder system
SIMOTICS M-1FE2 built-in motors
76 Hardware Installation Manual, 04/2020, A5E50074509B AA
4.3 Encoder system
The encoder is not included in the scope of delivery.
The spindle manufacturer is responsible for the selection and assembly.
Note
Additional informatio
n about the encoder is contained in the associated Configuration
Manual

Siemens SIMOTICS Series Specifications

General

Product brand name	SIEMENS
Product designation	SIMOTICS
Efficiency Class	IE1, IE2, IE3, IE4
Ambient Temperature	+60°C
Altitude	Up to 4000 m
Frame Size	63 to 355
Protection Class	IP55, IP56, IP65
