Siemens SINAMICS G120P Function Manual

Communication via PROFIBUS and PROFINET
3.7 Communication via PROFIBUS
Fieldbuses
Function Manual, 04/2018, FW V4.7 SP10, A5E34229197B AE
75
3.7.2
What do you have to set for communication via PROFIBUS?
Configuring PROFIBUS communication
You require the appropriate engineering system to configure PROFIBUS communication in
the PROFIBUS master.
If required, load the GSD file of the inverter into the engineering system.
Configuring communication to the control system (Page 76)
Setting the address
Set the address of the PROFIBUS slave.
Setting the address (Page 78)
Setting the telegram
Set the telegram in the inverter as in the PROFIBUS master. Interconnect the telegrams in
the control program of the PROFIBUS master with the signals of your choosing.
PROFIDRIVE profile - Cyclic communication (Page 17)
Application examples
You can find application examples for PROFIBUS communication on the Internet:
Controlling the speed of a SINAMICS G110M/G120/G120C/G120D with S7-300/400F
via PROFINET or PROFIBUS, with Safety Integrated (via terminal) and HMI
(https://support.industry.siemens.com/cs/ww/en/view/60441457)
Controlling the speed of a SINAMICS G110M / G120 (Startdrive) with S7-1500 (TO) via
PROFINET or PROFIBUS, with Safety Integrated (via terminal) and HMI
(https://support.industry.siemens.com/cs/ww/en/view/78788716)

Siemens SINAMICS G120P Specifications

General

Frequency Range	0 Hz to 550 Hz
Ambient Temperature	-10°C to +50°C
Storage Temperature	-40°C to +70°C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V, 380 V to 480 V, 500 V to 690 V
Output Voltage	0V to input voltage
Control Type	Vector control, V/f control
Protection Class	IP20, IP55
Communication Interfaces	PROFIBUS, PROFINET, Modbus RTU
Cooling Method	Air cooling
Altitude	Up to 2000 m without derating
Power Range	0.37 to 630 kW
