Siemens SINAMICS G120P Function Manual

Communication via EtherNet/IP
4.5 Supported objects
Fieldbuses
Function Manual, 04/2018, FW V4.7 SP10, A5E34229197B AE
89
Table 4- 4 Instance Attribute
No.
Service
Type
Name
Value/explanation
1
get
UINT16
Vendor ID
1251
2 get UINT16 Device Type
- ODVA AC Drive
- Siemens Drive
02 hex
12 hex
3
get
UINT16
Product code
r0964[1]
4
get
UINT16
Revision
The versions should match the EDS file
5
get
UINT16
Status
See the following table
6 get UINT32 Serial number bits 0 … 19: consecutive number;
bits 20 … 23: Production identifier
bits 24 … 27: Month of manufacture (0 = Jan, B =
Dec)
Bits 28 … 31: Year of manufacture (0 = 2002)
7 get Short
String
Product name max. length 32 bytes
e.g. SINAMICS G120
Table 4- 5 Explanation of No. 5 of the previous table
Byte
Bit
Name
Description
1 0 Owned 0: Inverter is not assigned to any master
1: Inverter is assigned to a master
1
Reserved
2 Configured 0: Ethernet/IP basic settings
1: Modified Ethernet/IP settings
For G120, always = 1
3
Reserved
4 … 7 Extended De-
vice Status
0: Self-test or status not known
1: Firmware update active
2: At least one I/O connection with error
3: No I/O connections
4: Incorrect configuration in the ROM
5: Fatal fault
6: At least one I/O connection is active
7: All I/O connections in the quiescent state
8 … 15: Reserved
2
8 … 11
Not used
12 … 15
Reserved

Siemens SINAMICS G120P Specifications

General

Frequency Range	0 Hz to 550 Hz
Ambient Temperature	-10°C to +50°C
Storage Temperature	-40°C to +70°C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V, 380 V to 480 V, 500 V to 690 V
Output Voltage	0V to input voltage
Control Type	Vector control, V/f control
Protection Class	IP20, IP55
Communication Interfaces	PROFIBUS, PROFINET, Modbus RTU
Cooling Method	Air cooling
Altitude	Up to 2000 m without derating
Power Range	0.37 to 630 kW
