Siemens SINUMERIK 808D - Page 104

Siemens SINUMERIK 808D
524 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
Description: Only when MD18080 $MN_MM_TOOL_MANAGEMENT_MASK, bit 0 = 1 or bit 1 = 1 and bit 2=1
('H4'), is set:
User or OEM data in the tool management.
Number of Siemens OEM monitoring data; standard format IN_Int).
See also: MD18098 $MN_MM_NUM_CC_MON_PARAM, MD18100 $MN_MM_NUM_CUTTING_EDGES_IN_TOA
Buffered user memory is used
18209 MM_TYPE_CCS_MON_PARAM N02, N09 FBWsl
- Type of Siemens OEM monitor data (SRAM) DWORD PowerOn
-
808d-me42 10 3, 3, 3, 3, 3, 3, 3, 3... 1 6 2/2 M
808d-me62 10 3, 3, 3, 3, 3, 3, 3, 3... 1 6 2/2 M
808d-te42 10 3, 3, 3, 3, 3, 3, 3, 3... 1 6 2/2 M
808d-te62 10 3, 3, 3, 3, 3, 3, 3, 3... 1 6 2/2 M
808d-mte40 10 3, 3, 3, 3, 3, 3, 3, 3... 1 6 0/0 S
808d-mte60 10 3, 3, 3, 3, 3, 3, 3, 3... 1 6 0/0 S
Description: Only when MD18080 $MN_MM_TOOL_MANAGEMENT_MASK, bit 0 = 1 or bit 1 = 1 and bit 2=1
('H4'), is set:
User or OEM data in the tool management.
Type of monitoring-specific Siemens user data configured by MD18208
$MN_MM_NUM_CCS_MON_PARAM.
Each parameter can be assigned its own type. The permissible types are
Type Value of the machine data
(See types of the NC language)
----------------------------------------------------------------
BOOL 1
CHAR 2
INT 3
REAL 4
(STRING is explicitly impossible here; value 5 is treated like value 2)
AXIS 6
FRAME not defined
See also: MD18208 $MN_MM_NUM_CCS_MON_PARAM, MD18100 $MN_MM_NUM_CUTTING_EDGES_IN_TOA
Buffered user memory is used. A change in value leads to reconfiguration of the
buffered memory.
18230 MM_USER_MEM_BUFFERED N02 S7
- Buffered user memory DWORD PowerOn
NDLD
808d-me42 - - 0 7168 0/0 S
808d-me62 - - 0 7168 0/0 S
808d-te42 - - 0 7168 0/0 S
808d-te62 - - 0 7168 0/0 S
808d-mte40 - - 0 7168 ReadOnly M
808d-mte60 - - 0 7168 ReadOnly M
Description: Nonvolatile user memory (in kB).
Various types of user data are stored in this memory area.
For example:
Machine data
3.2 General machine data
Parameter Manual
104 List Manual, 01/2017
