8
9
To the MCP
DB1100 To the MCP [r/w]
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Key 2 Key 1 MDA SINGLE
BLOCK
AUTO REF. POIN
T
JOG HAND
WHEEL
1 Feed over‐
ride key (-)
TAIL
STOCK
INT. EXT. CHUCK TOOL
CHANGE
COOLANT LAMP Key 3
2 100 (INC) /
100% G00
10 (INC) /
50% G00
1 (INC) /
25% G00
F0 G00 Key 5 Key 4 Feed over‐
ride key (+)
Feed over‐
ride key
(100%)
3 Axis tra‐
versing key
(↑x)
Spindle
override
key (-)
CYCLE
START
CYCLE
STOP
RESET SPINDLE
RIGHT
SPINDLE
STOP
SPINDLE
LEFT
4 M01 PRO‐
GRAM
TEST
Axis tra‐
versing key
(↓x)
Spindle
override
key (+)
Axis tra‐
versing key
(→z)
RAPID Axis tra‐
versing key
(←z)
Spindle
override
key (100%)
8 1
1)
1
1)
7 SEG LED1
2)
9 1
1)
1
1)
7 SEG LED2
2)
1)
To ensure the correct display of the active tool number, make sure that you set Bit 4 and Bit 5 to 1.
2)
You can set only values 0 to 9 for each 7-segment LED (LED1 and LED2).
6.3 Reading/Writing NC data
6.3.1 Reading/writing NC data: Job
DB1200
Reading/writing NC data [r/w]
PLC → NCK interface
Byte
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Write varia‐
ble
Start
1 Number of variables
2
3
DB1200 ...
1203
Reading/writing NC data [r/w]
PLC → NCK interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
1000 Variable index
PLC user interface
6.3 Reading/Writing NC data
Parameter Manual
List Manual, 01/2017 475
