Siemens SINUMERIK 808D - PI Service: Result; Retentive Data Area

4006 PI parameter 2
4008 PI parameter 3
4010 PI parameter 4
4012 PI parameter 5
4014 PI parameter 6
4016 PI parameter 7
4018 PI parameter 8
4020 PI parameter 9
4022 PI parameter 10
6.4.2 PI service: Result
DB1200 Reading / writing NC data [r]
NCK → PLC interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
5000 Error in job Job com‐
pleted
5001
5002
6.5 Retentive data area
DB1400 Retentive data [r/w]
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
User data
0
User data
1
User data
2
...
...
32
...
...
User data
126
User data
127
PLC user interface
6.5 Retentive data area
Parameter Manual
List Manual, 01/2017 477
