Bit7=1:
Is only active in the ISO mode turning. If T substitution ( MD10717
$MN_T_NO_FCT_CYCLE_NAME ) is active, the Siemens cutting edge number D corresponding
to the H number programmed in the T word is transferred to the cycle in the variable
$C_D.
10900 INDEX_AX_LENGTH_POS_TAB_1 N09 T1
- Number of positions for indexing axis table 1 DWORD Reset
-
- - 0 0 60 2/2 M
Description: The indexing position table is used to assign the axis positions in the valid unit of
measurement (mm, inches or degrees) to the indexing positions [n] on the indexing
axis. The number of indexing positions used in table 1 is defined by MD10900
$MN_INDEX_AX_LENGTH_POS_TAB_1.
These indexing positions must be assigned valid values in table 1. Any indexing
positions in the
table above the number specified in the machine data are ignored. Up
to 60 indexing positions (0 to 59) can be entered in the table.
Table length = 0 means that the table is not evaluated. If the length is not equal to
0, then the
table must be assigned to an axis with MD30500 $MA_INDEX_AX_ASSIGN_POS_TAB.
If the indexing axis is defined as a rotary axis (MD30300 $MA_IS_ROT_AX = "1") with
modulo 360° (MD30310 $MA_ROT_IS_MODULO = "1"), the machine data defines the last
indexing position after which, with a further traversing movement in the positive
direction, the indexing positions begin again at 1.
Special cases:
Alarm 17090 "Value violates upper limit" if values over 60 are entered in MD10900
$MN_INDEX_AX_LENGTH_POS_TAB_1.
Related to:
MD30500 $MA_INDEX_AX_ASSIGN_POS_TAB (axis is an indexing axis)
MD10910 $MN_INDEX_AX_POS_TAB_1 (indexing position table 1)
MD30300 $MA_IS_ROT_AX(rotary axis)
MD30310 $MA_ROT_IS_MODULO (modulo conversion for rotary axis)
10910 INDEX_AX_POS_TAB_1 N09 T1
mm/inch,
degrees
Indexing position table 1 DOUBLE Reset
-
- 60 0., 0., 0., 0., 0., 0., 0.,
0....
- - 2/2 M
Description: The indexing position table is used to assign the axis positions in the valid unit of
measurement (mm, inches
or degrees) to the indexing positions [n] on the indexing axis.
[n] = indexing for the entry of the indexing positions in the indexing position table.
Range: 0 y n x 59, where 0 corresponds to the 1st indexing position and 59 to the 60th
indexing position.
Note.
Programming with the absolute indexing position (e.g. CAC) starts with indexing
position 1. This corresponds to the indexing position with indexing n = 0 in the
indexing position table.
The following should be noted when entering the indexing positions:
Machine data
3.2 General machine data
Parameter Manual
List Manual, 01/2017 57
