corresponding to ... DB3300 DBX3.7 (channel status reset)
Note for the reader Function Manual Basic Functions K1
5.3.2 Signals from HMI
DB1800
DBX0.0
AUTOMATIC mode
Signal(s) to PLC (HMI → PLC)
Edge evaluation: Yes Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
AUTOMATIC mode is selected from the HMI.
The signal state 1 is only available for one PLC cycle.
Signal state 0 AUTOMATIC mode is not selected by HMI.
Signal irrelevant for ... if signal "Mode change disable"
Note for the reader Function Manual Basic Functions M5
DB1800
DBX0.1
MDI mode
Signal(s) to PLC (HMI → PLC)
Edge evaluation: Yes Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
MDI mode is selected from the HMI.
The signal state 1 is only available for one PLC cycle.
Signal state 0 MDI mode is not selected by HMI.
Signal irrelevant for ... if signal "Mode change disable"
Note for the reader Function Manual Basic Functions M5
DB1800
DBX0.2
JOG mode
Signal(s) to PLC (HMI → PLC)
Edge evaluation: Yes Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
JOG mode is selected from the HMI.
The signal state 1 is only available for one PLC cycle.
Signal state 0 JOG mode is not selected by HMI.
Signal irrelevant for ... if signal "Mode change disable"
Note for the reader Function Manual Basic Functions M5
DB1800
DBX0.7
Reset
Edge evaluation: Yes Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
A reset is initiated for the channel period. All of the current programs are
then in the program status "Aborted". All moving axes and spindles are
decelerated
to zero
speed according to their acceleration ramp without con‐
tour violation. The initial settings are set (e.g. for G functions). The alarms
are cleared if they are not POWER ON alarms.
Signal state 0 or edge
change 1 → 0
Channel status and program execution are not influenced by this signal.
Detailed descriptions of interface signals
5.3 Signals from / to HMI
Parameter Manual
380 List Manual, 01/2017
