Bit 3 == 1 Activation of program test with accelerated feed in the simulation.
Bit 4 == 1 Activation of accelerated program test takes place in synchronized multi-
channel mode.
Bit 5..31 As yet unused.
Program test with normal processing is always activated via the VDI interface.
Program test in simulation is always activated via the NCKMode PI.
Program test block search is always activated via the Find-Pi.
10709 PROG_SD_POWERON_INIT_TAB EXP, N01 K1
- Setting data to be initialized DWORD PowerOn
-
- 30 43200, 43202, 0, 0, 0,
0, 0, 0...
- - 2/2 M
Description: Setting data to be initialized:
The values of the programmable SD indicated in this MD are set to their initial values
on control power up.
Only the setting data listed in the table below, however, can be initialized. If
invalid
setting data numbers are configured, then the alarm 4009 is output at the next
run-up of the control. The alarm shows the index used for configuring the invalid
setting data. The alarm can only be eliminated by changing the invalid setting data,
i.e. by entering either a valid number or zero!
(GCODE)
SD42000 $SC_THREAD_START_ANGLE SF
SD42010 $SC_THREAD_RAMP_DISP DITS/DITE
SD42125 $SC_SERUPRO_SYNC_MASK
SD42400 $SC_PUNCH_DWELLTIME PDELAYON
SD42402 $SC_NIBPUNCH_PRE_START_TIME
SD42404 $SC_MINTIME_BETWEEN_STROKES
SD42800 $SC_SPIND_ASSIGN_TAB SETMS
SD43200 $SA_SPIND_S S wih G94,G95,G97,G971,G972
SD43202 $SA_SPIND_CONSTCUT_S S with G96,G961,G962
SD43210 $SA_SPIND_MIN_VELO_G25 G25 S
SD43220 $SA_SPIND_MAX_VELO_G26 G26 S
SD43230 $SA_SPIND_MAX_VELO_LIMS LIMS
SD43235 $SA_SPIND_USER_VELO_LIMIT
SD43300 $SA_ASSIGN_FEED_PER_REV_SOURCE FPRAON
SD43350 $SA_AA_OFF_LIMIT
SD43420 $SA_WORKAREA_LIMIT_PLUS G26
SD43430 $SA_WORKAREA_LIMIT_MINUS G25
SD43600 $SA_IPOBRAKE_BLOCK_EXCHANGE
SD43610 $SA_ADISPOSA_VALUE
SD43700 $SA_OSCILL_REVERSE_POS1 OSP1
SD43710 $SA_OSCILL_REVERSE_POS2 OSP2
SD43720 $SA_OSCILL_DWELL_TIME1 OST1
SD43730 $SA_OSCILL_DWELL_TIME2 OST2
SD43740 $SA_OSCILL_VELO FA
SD43750 $SA_OSCILL_NUM_SPARK_CYCLES OSNSC
SD43760 $SA_OSCILL_END_POS OSE
SD43770 $SA_OSCILL_CTRL_MASK OSCTRL
SD43780 $SA_OSCILL_IS_ACTIVE OS
Machine data
3.2 General machine data
Parameter Manual
44 List Manual, 01/2017
