Alarm suppression operating range limit in the basic coordinate system in JOG.
Alarms that would be output in JOG when an operating range limit is reached in the
basic coordinate system, are suppressed.
Bit 5:
Alarm suppression operating range limit in the workpiece coordinate system in JOG.
Alarms that would be output in JOG when an operating range limit is reached in the
workpiece coordinate system, are suppressed.
Bit 6, 7:
JOG of circles:
Bit 7 and bit 6 = 0: traversing the 2nd geometry axis of the active plane to PLUS for
radius increase, traversing to MINUS for radius decrease independently of inner or
outer machining being active.
Bit 7 = 1 and bit 6 = 0: traversing the 2nd geometry axis of the active plane to PLUS
always
travels in
the direction of the limiting circle. This means that the radius is
increased on inner machining and decreased on outer machining.
Bit 7 = 1 and bit 6 = 1: traversing the 2nd geometry axis of the active plane to MINUS
always travels in
the direction of the limiting circle. This means that the radius is
increased on inner machining and decreased on outer machining.
Bit 8:
Bit 8 = 0 If there is a JOG retract movement, the retraction axis can only be jogged
in the plus direction.
Bit 8 = 1 If there is a JOG retract movement, the retraction axis can only be jogged
in the plus and minus direction.
Bits 9-31:
Currently unassigned.
10760 G53_TOOLCORR N12 FBFA
- Method of operation of G53, G153 and SUPA DWORD NEW CONF
-
- - 0 0 0x3 2/2 M
Description: With this MD you define whether tool length offset and tool radius offset are also to
be suppressed with language commands G53, G153 and SUPA
The machine data is bit-coded.
Bit 0 = 0: G53, G153 and SUPA cause block-by-block suppression of work offsets. The
active tool length offset and tool radius offset remain active.
Bit 0 = 1: G53, G153 and SUPA cause block-by-block suppression of work offsets, active
tool length offset and tool radius offset. The tool length behavior can be modified
with bit 1.
Bit 1 is only evaluated, if the value of bit 0 is 1.
Bit1 = 0: with bit 0 set, the tool length is always suppressed with G53, G153 and SUPA.
Bit1 = 1: with bit 0 set the tool length is only suppressed with G53, G153 and SUPA,
if
a cutting
edge is not selected in the same block (this can also be the cutting edge
that is already active).
10808 EXTERN_INTERRUPT_BITS_M96 EXP, N12 FBFA
- Activate interrupt program (ASUB) DWORD PowerOn
-
- - 0 0 0x7FFFFFFF 1/1 M
Description: Setting the various bits can influence the processing of the interrupt routine
activated by M96 P...
Bit 0 = 0,
No interrupt program possible, M96/M97 are normal M functions
Bit 0 = 1,
Machine data
3.2 General machine data
Parameter Manual
List Manual, 01/2017 51
