Siemens SINUMERIK 808D Parameter Manual

808d-me62 5 MX1, MY1, MZ1,
MSP1, MA1
- - 2/2 M
808d-te42 4 MX1, MZ1, MSP1, MC1 - - 2/2 M
808d-te62 5 MX1, MZ1, MSP1, MC1 - - 2/2 M
808d-mte40 4 X1, Y1, Z1, A1 - - 2/2 M
808d-mte60 5 X1, Y1, Z1, A1, B1 - - 2/2 M
Description: List of the machine axis identifiers
The name of the machine axis is entered in this MD.
In addition to the fixed, defined machine axis identifiers "AX1", "AX2" ..., user-
defined identifiers for the machine axes can also be assigned in this data.
The identifiers defined here can be used parallel to the fixed, defined identifiers
for addressing axial data (e.g. MD) and machine axis-related NC functions (reference
point approach, axial measurement, travel to fixed stop).
Special cases:
● The
input machine axis name must not conflict with the names and assignments of the
geometry axes (MD20060 $MC_AXCONF_GEOAX_NAME_TAB, MD20050
$MC_AXCONF_GEOAX_ASSIGN_TAB) and
channel axes (MD20080 $MC_AXCONF_CHANAX_NAME_TAB,
MD20070 $MC_AXCONF_MACHAX_USED).
The input machine axis name must not conflict with
● The
input machine axis name must not include any of the following reserved address
letters:
D Tool offset (D function) E Reserved
F V Feedrate (F function) G Path condition
H Auxiliary function (H function) L Subroutine call
M Miscellaneous function (M function) N Subblock
P Subroutine number of passes R Arithmetic parameters
S Spindle speed (S function) T Tool (T function)
The name must not include any keywords (e.g. DEF, SPOS etc.) or pre-defined
identifiers (e.g. ASPLINE, SOFT).
The use
of an axis identifier consisting of a valid address letter (A, B, C, I, J, K,
Q,
U, V,
W, X, Y, Z), followed by an optional numerical extension (1-99) gives slightly
better block change times than a general identifier.
If no identifier is assigned to a machine axis, the predefined name ("AXn") applies to
the nth machine axis).
Related to....
MD20060 $MC_AXCONF_GEOAX_NAME_TAB (geometry axis name in the channel [GEOAxisno.]
MD20080 $MC_AXCONF_CHANAX_NAME_TAB (channel axis name in the channel [Channelaxisno.]
10050 SYSCLOCK_CYCLE_TIME N01, N05, N11 G3, G2, R1
s System clock cycle DOUBLE PowerOn
SFCO
808d-me42 - 0.002 0.001 0.008 0/0 S
808d-me62 - 0.004 0.001 0.008 0/0 S
808d-te42 - 0.002 0.001 0.008 0/0 S
808d-te62 - 0.004 0.001 0.008 0/0 S
808d-mte40 - 0.002 0.001 0.008 7/2 M
808d-mte60 - 0.004 0.001 0.008 7/2 M
Description: Basic cycle time of the system software
The cycle time settings of cyclical tasks (position controller/IPO) are multiples of
this basic cycle.
Machine data
3.2 General machine data
Parameter Manual
List Manual, 01/2017 33
