1001 INT2
ASUP exe‐
cution not
possible
Interrupt
no. not allo‐
cated
ASUP is be‐
ing execu‐
ted
ASUP
ended
1002
1003
G functions from NCK channel
DB3500 G functions from NCK channel [r]
NCK → PLC interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Active G function of group 1 (8 bit int)
1 Active G function of group 2 (8 bit int)
2 Active G function of group 3 (8 bit int)
... ...
62 Active G function of group 63 (8 bit int)
63 Active G function of group 64 (8 bit int)
6.11 Axis/spindle signals
6.11.1 Transferred M and S functions, axis specific
DB3700 … 3703 M, S functions [r]
NCK -> PLC interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 M function for spindle (DINT)
4 S function for spindle (REAL)
6.11.2 Signals to axis/spindle
Common signals to axis/spindle
DB3800 ...
3803
Signals to axis/spindle [r/w]
PLC -> NCK interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Feedrate override
H G F E D C B A
PLC user interface
6.11 Axis/spindle signals
Parameter Manual
496 List Manual, 01/2017
