Siemens SINUMERIK 808D Parameter Manual

4003 No tool
change
command
active
DELAY
FST SUP‐
PRESS
DELAY
FST
4004 ProgEvent display
Start after
block
search
Boot Operator
panel
Reset
Part pro‐
gram
End
Part pro‐
gram
Start from
RESET
4005 Jog circle
Active
Stop condi‐
tion
StopByColl
Danger
4006 Dormant
ASUP
Active
ASUP ac‐
tive
4007
4008 Active transformation number
4009 Reserved
4010 Reserved
4011 Reserved
Asynchronous subroutines (ASUPs): Job
DB3400 ASUP: Result [r/w]
PLC → NCK interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 INT1
Start
1 INT2
Start
2
3
Asynchronous subroutines (ASUPs): Result
DB3400 ASUP: Result [r]
NCK → PLC interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
1000 INT1
ASUP exe‐
cution not
possible
Interrupt
no. not allo‐
cated
ASUP is be‐
ing execu‐
ted
ASUP
ended
PLC user interface
6.10 Channel signals
Parameter Manual
List Manual, 01/2017 495
