1002
1003
Contour
handwheel
direction of
rotation in‐
verted
1004 Axis 2 in Work
Traversing command Travel request Handwheel active (bit/binary coded)
Plus Minus Plus Minus 2 1
1005 Axis 2 in Work
Machine function
Continuous
traversing
Var. INC 10000 INC 1000 INC 100 INC 10 INC 1 INC
1006
1007
Contour
handwheel
direction of
rotation in‐
verted
1008 Axis 3 in Work
Traversing command Travel request Handwheel active (bit/binary coded)
Plus Minus Plus Minus 2 1
1009 Axis 3 in Work
Machine function
Continuous
traversing
Var. INC 10000 INC 1000 INC 100 INC 10 INC 1 INC
1010
1011 Contour
handwheel
direction of
rotation in‐
verted
Additional status signals from NC channel
DB3300 Signals from NCK channel [r]
NCK → PLC interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
4000 G00 active
4001 Travel re‐
quest, drive
test present
Workpiece
setpoint
reached
External
language
mode
active
4002 Dry run fee‐
drate
Active
Associated
M01/M00
Active
STOP_DE‐
LAYED
ASUP is
stopped
PLC user interface
6.10 Channel signals
Parameter Manual
494 List Manual, 01/2017
