Siemens SINUMERIK 808D Parameter Manual

3.3 Channel-specific machine data
20050 AXCONF_GEOAX_ASSIGN_TAB C01, C10 TE7, TE8, M1, R2, K1, K2
- Assignment of geometry axis to channel axis BYTE PowerOn
-
808d-me42 3 1, 2, 3, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 20 1/1 M
808d-me62 3 1, 2, 3, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 20 1/1 M
808d-te42 3 1, 0, 2 0 20 1/1 M
808d-te62 3 1, 0, 2 0 20 1/1 M
808d-mte40 3 1, 2, 3, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 20 1/1 M
808d-mte60 3 1, 2, 3, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
0 20 1/1 M
Description: This MD is used to specify which channel axis the geometry axis is assiged to. Each
geometry axis must be assigned to a specific channel. If a geometry axis is not
assigned to a channel axis, then this geometry axis is not available, and cannot be
programmed (with the name defined under MD20060 $MC_AXCONF_GEOAX_NAME_TAB).
For example: Turning machine without transformation:
MD20050 $MC_AXCONF_GEOAX_ASSIGN_TAB[ 0 ] = 1 ; 1st geometry axis = 1st channel axis
MD20050 $MC_AXCONF_GEOAX_ASSIGN_TAB[ 1 ] = 0 ; 2nd geometry axis not defined
MD20050 $MC_AXCONF_GEOAX_ASSIGN_TAB[ 2 ] = 2 ; 3rd geometry axis = 2nd channel axis
The assignment made here is valid if no transformation is active. With active
transformation n, the transformation-specific assignment table MD24...
$MC_TRAFO_GEOAX_ASSIGN_TAB_... becomes active.
20060 AXCONF_GEOAX_NAME_TAB C01, C11, C10 F2, V2, M1, K2
- Geometry axis name in channel STRING PowerOn
-
808d-me42 3 X, Y, Z, X, Y, Z, X, Y, Z,
X,
Y, Z,
X, Y, Z, X, Y, Z,
X, Y, Z, X...
- - 1/1 M
808d-me62 3 X, Y, Z, X, Y, Z, X, Y, Z,
X, Y, Z,
X, Y, Z, X, Y, Z,
X, Y, Z, X...
- - 1/1 M
808d-te42 3 X, , Z - - 1/1 M
808d-te62 3 X, , Z - - 1/1 M
808d-mte40 3 X, Y, Z, X, Y, Z, X, Y, Z,
X,
Y, Z,
X, Y, Z, X, Y, Z,
X, Y, Z, X...
- - 1/1 M
808d-mte60 3 X, Y, Z, X, Y, Z, X, Y, Z,
X, Y, Z,
X, Y, Z, X, Y, Z,
X, Y, Z, X...
- - 1/1 M
Description: This MD is used to enter the names of the geometry axes separately for each channel.
Geometry axes can be programmed in the part program using the names specified here.
Special cases:
Machine data
3.3 Channel-specific machine data
Parameter Manual
118 List Manual, 01/2017
