Description: The filter time indicates the time during which the pulses from the handwheel are
output to the interpolator. The values are incremented internally in interpolation
cycles.
In the case of a filter time setting = 0.0, the pulses from the handwheel are output
to the interpolator
within a single interpolation cycle. This can cause the controlled
axis to exhibit jerk during traversing.
Machine data is valid for the following types of handwheel (see 11350
$MN_HANDWHEEL_SEGMENT):
SEGMENT_ETHERNET:
● Recommended filter time: 0.2 - 0.5 s
11414 ALARM_CLR_NCSTART_W_CANCEL EXP, N01 D1
- Clear NCSTART alarms with CANCEL BOOLEAN PowerOn
-
808d-me42 - FALSE 0 - 0/0 S
808d-me62 - FALSE 0 - 0/0 S
808d-te42 - FALSE 0 - 0/0 S
808d-te62 - FALSE 0 - 0/0 S
808d-mte40 - FALSE 0 - 7/2 M
808d-mte60 - FALSE 0 - 7/2 M
Description: If this MD is set, then alarms that have ClearInfo=NCSTART are cleared by the Alarm
Cancel button as well as by NC-Start.
If this MD is not set, then NCSTART alarms are not cleared by Cancel.
The purpose of this MD is to provide compatibility with system behavior.
11450 SEARCH_RUN_MODE EXP, N01 K1, TE3, N4, H2, Z1
- Parameterization for search run DWORD PowerOn
-
- - 0x40 0 0xFF 1/1 M
Description: The behavior during the action blocks after block search can be affected by the
following bits:
Bit 0 = 0:
Machining is stopped after loading of the last action block after block search, the NC/
PLC interface signal DB3300 DBX0.6 (last action block active) is set and alarm 10208
is output.
Bit 0 = 1:
Machining is stopped with the loading of the last action block after block search, and
the NC/PLC interface signal DB3300 DBX0.6 (last action block active) is set. Alarm
10208 is not output until the PLC requests it by setting the NC/PLC interface signal
DB3200 DBX1.6 (PLC action finished).
Application:
Starting an ASUB from the PLC after block search.
The message to the operator that another NC start is required in order to continue with
the program is not to be displayed until after the end of the ASUB.
Bit 1 = 1
Automatic ASUB start after output of the action blocks. Alarm 10208 is not output until
the ASUB has finished.
Bit 2 = 0:
Spindle: auxiliary functions are output in the action blocks.
Bit 2 = 1:
Machine data
3.2 General machine data
Parameter Manual
72 List Manual, 01/2017
