10074 PLC_IPO_TIME_RATIO N01, N05 -
- Factor of PLC task for the main run. DWORD PowerOn
-
- - 1 1 50 2/2 M
Description: Division ratio between IPO and PLC tasks.
A value of 2 means, e. g. that the PLC task is only processed in every second IPO
cycle.
The PLC
cycle time is then 2 IPO cycle times. This makes more runtime available
for the other tasks.
The PLC run time must not exceed this PLC cycle time, otherwise an alarm with PLC STOP
is triggered.
10075 PLC_CYCLE_TIME N01, N05 -
- PLC cycle time DOUBLE PowerOn
-
- - 0.0 - - ReadOnly M
Description: Display of the PLC cycle time (not modifiable, is internally generated)
10131 SUPPRESS_SCREEN_REFRESH EXP A2
- Screen refresh response under overload BYTE PowerOn
-
808d-me42 - 2 0 2 0/0 S
808d-me62 - 2 0 2 0/0 S
808d-te42 - 2 0 2 0/0 S
808d-te62 - 2 0 2 0/0 S
808d-mte40 - 2 0 2 7/2 M
808d-mte60 - 2 0 2 7/2 M
Description: There are part programs in which the main run (HL) has to wait until the pre-processing
(VL) makes new blocks available.
The pre-processing and display update compete for NC computing time. The MD defines
how the NC is to respond when the pre-processing is too slow.
0: When the VL of a channel is too slow, the updating of the display is suppressed
in all channels.
1: When the VL of a channel is too slow, the updating of the display is suppressed
only in the time-critical channels in order to gain time for the pre-processing.
2: The updating of the display is never suppressed.
10136 DISPLAY_MODE_POSITION N01 -
- Display mode for actual position in the work DWORD Reset
-
808d-me42 - 1 0 1 1/1 M
808d-me62 - 1 0 1 1/1 M
808d-te42 - 1 0 1 1/1 M
808d-te62 - 1 0 1 1/1 M
808d-mte40 - 0 0 1 1/1 M
808d-mte60 - 0 0 1 1/1 M
Description: Defines how the position and the distance to go are displayed in the Work.
0: Display as in software version 5 and earlier
Machine data
3.2 General machine data
Parameter Manual
List Manual, 01/2017 35
