10890 EXTERN_TOOLPROG_MODE N12 FBFA
- Tool change programming for external language DWORD PowerOn
-
808d-me42 - 0x0 0 0x7FFFFFFF 2/2 M
808d-me62 - 0x0 0 0x7FFFFFFF 2/2 M
808d-te42 - 0x04 0 0x7FFFFFFF 2/2 M
808d-te62 - 0x04 0 0x7FFFFFFF 2/2 M
808d-mte40 - 0x0 0 0x7FFFFFFF 2/2 M
808d-mte60 - 0x0 0 0x7FFFFFFF 2/2 M
Description: Configuration for programming the tool change in an external programming language:
Bit0=0:
Only active for the ISO mode turning: The tool number and offset number are programmed
in
the T
word. $MN_DIGITS_TOOLNO defines the number of leading digits, which form the
tool number.
Example:
$MN_DIGITS_TOOLNO = 2
T=1234 ; tool number 12,
; offset number 34
Bit0=1:
Only active in the ISO mode turning: Only the tool number is programmed in the T word.
Offset number == tool number. $MN_DIGITS_TOOLNO is irrelevant.
Example:
T=12 ; tool number 12
; offset number 12
Bit1=0:
Only active in the ISO mode turning:
If the number of digits programmed in the T word is the same as the number defined in
MD10888 $MN_EXTERN_DIGITS_TOOL_NO, then leading 0s are added
Bit1=1:
Is only active for the ISO mode turning:
If the number of digits programmed in the T word is the same as the number of digits
specified in MD10888 $MN_EXTERN_DIGITS_TOOL_NO, the programmed number is the offset
number and tool number
Bit2=0:
Is only active for the ISO mode turning: ISO T offset selection only with D (Siemens
cutting edge number)
Bit2=1:
Is only active for the ISO mode turning: ISO T offset selection only with H
($TC_DPH[t,d])
Bit6=0:
The offset memories for the tool length and tool radius are linked so
that
tool length
and tool radius are always selected when either H or D is programmed.
Bit6=1:
The offset memories for the tool length and tool radius are not linked,
so
that the
number of the tool length value is selected when H is programmed, and the
number of the tool radius value is selected when D is programmed.
Bit7=0:
Is only active for the ISO mode turning. If T substitution ( MD10717
$MN_T_NO_FCT_CYCLE_NAME ) is active, the H number programmed in the T word is
transferred to the cycle in the variable $C_D.
Machine data
3.2 General machine data
Parameter Manual
56 List Manual, 01/2017
