Siemens SINUMERIK 808D Parameter Manual

808d-mte40 6 128, 128, 128, 128,
128, 128, 0, 0
0 128 7/2 M
808d-mte60 8 128, 128, 128, 128,
128, 128, 128, 128
0 128 7/2 M
Description: The MD defines the memory space available for the compensation tables.
When MD18342 $MN_MM_CEC_MAX_POINTS = 0, no memory is set up for the table. The sag
compensation function cannot then be used.
Caution!
If MD18342 $MN_MM_CEC_MAX_POINTS[t] is changed, when the system is powered up, the
buffered NC user memory is automatically reset. This deletes all user data in the
buffered user memory (e.g. drive and HMI machine data, tool offsets, part programs
etc.).
Related to:
SD41300 $SN_CEC_TABLE_ENABLE[t]
Evaluation of the sag compensation table (t) enabled.
References:
/FB/, S7, "Memory Configuration"
18352 MM_U_FILE_MEM_SIZE EXP, N02 S7
- End user memory for part programs/cycles/files DWORD PowerOn
-
808d-me42 3 1280, 0, 0 0 1280 0/0 S
808d-me62 3 1280, 0, 0 0 1280 0/0 S
808d-te42 3 1280, 0, 0 0 1280 0/0 S
808d-te62 3 1280, 0, 0 0 1280 0/0 S
808d-mte40 3 1280, 0, 0 0 1280 2/2 M
808d-mte60 3 1280, 0, 0 0 1280 2/2 M
Description: The machine data is not available or not defined for PowerLine control models.
End user memory for files in the passive file system ( in kbyte ).
There are various types of user data in this memory area.
E.g.: NC part programs, cycle programs of the end user, diagnostic files, ....
The settable values depend on the hardware and software configurations.
The settable size of the part program memory is, apart from the upper limit value,
determined by the MD18230 $MN_MM_USER_MEM_BUFFERED and can also
be determined by a software option.
Index 0 = Size of the battery-backed part program / cycle program memory
Index 1 = Reserved
Index 2 = Reserved
18353 MM_M_FILE_MEM_SIZE EXP, N02 S7
- Memory capacity for machine manufacturer's cycles/files DWORD PowerOn
-
808d-me42 3 160, 0, 0 0 256 0/0 S
808d-me62 3 160, 0, 0 0 256 0/0 S
808d-te42 3 160, 0, 0 0 256 0/0 S
808d-te62 3 160, 0, 0 0 256 0/0 S
808d-mte40 3 160, 0, 0 0 256 1/1 M
808d-mte60 3 160, 0, 0 0 256 1/1 M
Description: The machine data is not available or not defined for PowerLine control models.
Memory for machine manufacturer files in the passive file system ( in kbyte ).
Machine data
3.2 General machine data
Parameter Manual
106 List Manual, 01/2017
