Siemens SINUMERIK 808D Parameter Manual

18360 MM_EXT_PROG_BUFFER_SIZE N01 B1, K1
- FIFO buffer size for processing from external source (DRAM) DWORD PowerOn
-
808d-me42 - 100 30 1000000 0/0 S
808d-me62 - 200 30 1000000 0/0 S
808d-te42 - 100 30 1000000 0/0 S
808d-te62 - 100 30 1000000 0/0 S
808d-mte40 - 50 30 1000000 7/2 M
808d-mte60 - 50 30 1000000 7/2 M
Description: A FIFO buffer is needed on the NCK for each program level (main program or subprogram)
that is processed externally (reload mode).
The size of the FIFO buffer is defined in kbyte by MD18360 $MN_MM_EXT_PROG_BUFFER_SIZE.
MD18360 $MN_MM_EXT_PROG_NUM sets the number of FIFO buffers which are simultaneously
available.
During startup, the memory size determined by multiplying MD18360
$MN_MM_EXT_PROG_BUFFER_SIZE by MD18362 $MN_MM_EXT_PROG_NUM is reserved in the DRAM.
If the stated value exceeds the available memory space, alarm 4077 is output when
writing the machine data.
References:
/PGA/Programming Guide Advanced, Section 2
18362 MM_EXT_PROG_NUM N01 K1
- Number of program levels which can be simultaneously processed BYTE PowerOn
-
808d-me42 - 1 0 13 0/0 S
808d-me62 - 2 2 3 1/1 M
808d-te42 - 1 0 13 0/0 S
808d-te62 - 1 0 13 0/0 S
808d-mte40 - 1 0 13 7/2 M
808d-mte60 - 1 0 13 7/2 M
Description: Number of program levels that can simultaneously be in "Processing from external
source" mode NCK-wide.
System resources are reserved for the HMI <-> NCK communication during "Processing
from external source". Machine data MD18362$MN_EXT_PROG_NUM defines the number of
possible program levels.
The memory space is reserved during power on by MD18360 $MN_MM_EXT_PROG_BUFFER_SIZE *
MD18362 $MN_MM_EXT_PROG_NUM. If it is found during program execution that all system
resources are occupied, this is reported by alarm 14600.
18370 MM_PROTOC_NUM_FILES N02 D1, OEM
- Max.no. of log files in passive file system DWORD PowerOn
-
- 10 2, 2, 0, 0, 0, 2, 2, 2... 2, 2, 0, 0, 0, 2, 2,
2...
10, 10, 10, 10,
10, 10, 10, 10...
1/1 M
Description: Maximum number of log files in the passive file system.
The individual values involve the users of the logging function, which are assigned
the following functions:
0: Reserved for system functions: simultaneous recording, simulation, synchronized
actions analysis
1: Reserved for system functions: determining program runtimes, multi-step editor
Machine data
3.2 General machine data
Parameter Manual
108 List Manual, 01/2017
