Siemens SINUMERIK 808D Parameter Manual

20090 SPIND_DEF_MASTER_SPIND C01, C03 H2, K1, K2, P3 pl, P3 sl, S1, W1
- Initial setting of master spindle in channel BYTE PowerOn
-
- - - 1 1 1/1 M
Description: Definition of the default setting for the master spindle (in the channel).
The number of the spindle is entered.
A number of functions are linked to the master spindle, which are not possible with
any other spindle.
Note:
The language command SETMS(n) can declare the spindle number as the master spindle.
The spindle defined in this MD is declared once again as the master spindle with SETMS.
The spindle defined in this MD is also declared as the master spindle at program end
and program cancelation.
20094 SPIND_RIGID_TAPPING_M_NR C01, C03, C10 H2, K1, S1
- M function for switching into controlled axis mode DWORD PowerOn
-
- - 70, 70, 70, 70, 70, 70,
70, 70...
- - 2/2 M
Description: This machine data defines the M auxiliary function number with which the spindle is
switched into axis mode.
The M number defined in the machine data replaces M70 in Siemens mode.
Note:
On the VDI interface, M70 is always output with the corresponding address extension to
indicate the switch to axis mode.
Restrictions: Refer to machine data MD10715 $MN_M_NO_FCT_CYCLE
Related to:
MD10714 $MN_M_NO_FCT_EOP,
MD10715 $MN_M_NO_FCT_CYCLE,
MD20094 $MC_SPIND_RIGID_TAPPING_M_NR,
MD22254 $MC_AUXFU_ASSOC_M0_VALUE
MD10814 $MN_EXTERN_M_NO_MAC_CYCLE,
MD20095 $MC_EXTERN_RIGID_TAPPING_M_NR
20095 EXTERN_RIGID_TAPPING_M_NR C01, C11, C03,
C10
H2, K1
- M function for switching to controlled axis mode(external mode) DWORD PowerOn
-
- - 29, 29, 29, 29, 29, 29,
29, 29...
- - 2/2 M
Description: This machine data defines the M function number with which the switchover to
controlled spindle/axis mode is to be carried out.
The M number defined in the machine data replaces M29 in external language mode.
Pre-defined M numbers, such as M00,M1,M2,M3, etc., are not allowed as M numbers.
Restrictions: See machine data MD10715 $MN_M_NO_FCT_CYCLE
Related to:
MD10714 $MN_M_NO_FCT_EOP,
MD10715 $MN_M_NO_FCT_CYCLE,
MD20094 $MC_SPIND_RIGID_TAPPING_M_NR,
MD22254 $MC_AUXFU_ASSOC_M0_VALUE
Machine data
3.3 Channel-specific machine data
Parameter Manual
List Manual, 01/2017 121
