808d-mte40 4 0x7FFFFFFF,
0x7FFFFFFF,
0x7FFFFFFF,
0x7FFFFFFF,
0x7FFFFFFF,, 0x7...
0 0x7FFFFFFF 1/1 M
808d-mte60 20 0x7FFFFFFF,
0x7FFFFFFF,
0x7FFFFFFF,
0x7FFFFFFF,
0x7FFFFFFF,, 0x7...
0 0x7FFFFFFF 1/1 M
Description: Identifies whether the axis will be displayed by the HMI as a machine, geometry, or
auxiliary axis.
This data is only evaluated by the HMI.
Bit 0 to 15: Machine (MCS)
Bit 0= 1 Machine - display machine axis in the actual value windows
0 Machine - hide machine axis in the actual value windows
Bit 1= 1 Machine - display machine axis in the reference point window
0 Machine - hide machine axis in the reference point window
Bit 2= 1 Machine - display machine axis in preset/scratch/parameter work offset windows
0 Machine - hide machine axis in preset/scratch/parameter work offset windows
Bit 3= 1 Machine - display machine axis in the handwheel selection window
0 Machine - hide machine axis in the handwheel selection window
(Bit 4) Not assigned
Bit 5= 1 Display spindle in the T,F,S window
0 Hide spindle in the T,F,S window
Bit 16 to 31: Work (WCS)
Bit 16= 1 Work - display geometry axis in the actual value windows
0 Work - hide geometry axis in the actual value windows
(Bit 17) Not assigned
Bit 18= 1 Work - display geometry axis in parameter work offset window
0 Work - hide geometry axis in parameter work offset window
Bit 19= 1 Work - display geometry axis in the handwheel selection window
0 Work - hide geometry axis in the handwheel selection window
Bit 20= 1 Work - display position axis in the position/straight line windows
0 Work - hide position axis in the position/straight line windows
(Bit 21) Not assigned
20100 DIAMETER_AX_DEF C01, C10 H1, M5, P1, V1, W1
- Geometry axis with transverse axis function STRING PowerOn
-
808d-me42 - - - - 1/1 M
808d-me62 - - - - 1/1 M
808d-te42 - X - - 1/1 M
808d-te62 - X - - 1/1 M
808d-mte40 - - - - 1/1 M
808d-mte60 - - - - 1/1 M
Description: This MD is used to define a geometry axis as a transverse axis. Only one transverse
axis can be defined here for each channel.
Further transverse axes for axis-specific diameter programming can be activated via
MD30460 $MA_BASE_FUNCTION_MASK, bit 2.
Machine data
3.3 Channel-specific machine data
Parameter Manual
List Manual, 01/2017 123
