20154 EXTERN_GCODE_RESET_VALUES C11, C03 -
- Initial setting of G groups in ISO mode BYTE Reset
-
808d-me42 31 1, 1, 1, 2, 1, 1, 1, 3, 4,
1, 1, 2, 2, 1, 3, 2, 1, 0,
1, 1, 1,, ...
0 - 1/1 M
808d-me62 31 1, 1, 1, 2, 1, 1, 1, 3, 4,
1, 1, 2, 2, 1, 3, 2, 1, 0,
1, 1, 1,, ...
0 - 1/1 M
808d-te42 31 1, 2, 1, 2, 2, 1, 1, 0, 2,
1, 1, 2, 1, 1, 1, 2, 1, 0,
1, 1, 1,
0 - 1/1 M
808d-te62 31 1, 2, 1, 2, 2, 1, 1, 0, 2,
1, 1, 2, 1, 1, 1, 2, 1, 0,
1, 1, 1,
0 - 1/1 M
808d-mte40 31 1, 1, 1, 2, 1, 1, 1, 3, 4,
1, 1, 2, 2, 1, 3, 2, 1, 0,
1, 1, 1,, ...
0 - 1/1 M
808d-mte60 31 1, 1, 1, 2, 1, 1, 1, 3, 4,
1, 1, 2, 2, 1, 3, 2, 1, 0,
1, 1, 1,, ...
0 - 1/1 M
Description: When an external NC programming language is used, the G codes which become active on
runup and reset or at part program end are defined as a function of MD20110
$MC_RESET_MODE_MASK and at part program start as a function of MD20112
$MC_START_MODE_MASK.
The following external programming languages are possible:
ISO mode Milling
ISO mode Turning
The G group division that is to be used is stated in the current SINUMERIK
documentation.
The following groups within MD20154 $MC_EXTERN_GCODE_RESET_VALUES can be written:
ISO mode M:
G group 2: G17/G18/G19
G group 3: G90/G91
G group 5: G94/G95
G group 6: G20/G21
G group 13: G96/G97
G group 14: G54-G59
ISO mode T:
G group 2: G96/G97
G group 3: G90/G91
G group 5: G94/G95
G group 6: G20/G21
G group 16: G17/G18/G19
20156 EXTERN_GCODE_RESET_MODE C03 -
- Reset response of external G groups BYTE Reset
-
- 31 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0,, ...
0 1 1/1 M
Description: This MD is evaluated only if bit0 is set in MD20110 $MC_RESET_MODE_MASK (see there).
Machine data
3.3 Channel-specific machine data
Parameter Manual
List Manual, 01/2017 141
