Siemens SINUMERIK 808D Parameter Manual

20173 SURF_VELO_TOL C09 -
mm/min Maximum permitted deviation of the path feed on compression
with COMPSURF
DOUBLE PowerOn
-
808d-me42 - 1000.0, 1000.0,
1000.0, 1000.0,
1000.0, 1000.0,
1000.0, 1000.0...
0.0 - 1/1 M
808d-me62 - 1000.0, 1000.0,
1000.0, 1000.0,
1000.0, 1000.0,
1000.0, 1000.0...
0.0 - 1/1 M
808d-te42 - 1000.0, 1000.0,
1000.0, 1000.0,
1000.0, 1000.0,
1000.0, 1000.0...
0.0 - 0/0 S
808d-te62 - 1000.0, 1000.0,
1000.0, 1000.0,
1000.0, 1000.0,
1000.0, 1000.0...
0.0 - 0/0 S
808d-mte40 - 1000.0, 1000.0,
1000.0, 1000.0,
1000.0, 1000.0,
1000.0, 1000.0...
0.0 - 7/2 M
808d-mte60 - 1000.0, 1000.0,
1000.0, 1000.0,
1000.0, 1000.0,
1000.0, 1000.0...
0.0 - 7/2 M
Description: The value specifies the maximum permitted deviation for compression for the path feed.
The larger the value, the more short blocks can be compressed into one long block.
20180 TOCARR_ROT_ANGLE_INCR C08 W1
- Rotary axis increment of orientable tool holder DOUBLE NEW CONF
-
808d-me42 2 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0,...
- - 7/3 M
808d-me62 2 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0,...
- - 7/3 M
808d-te42 2 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0,...
- - 7/3 M
808d-te62 2 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0,...
- - 7/3 M
808d-mte40 2 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0,...
- - 0/0 M
808d-mte60 2 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0,...
- - 0/0 M
Description: For orientable tool carriers, this machine data defines the size of the minimum
increment (in degrees) by which the first or second orientation axis can be changed
(e.g. for Hirth tooth systems).
Machine data
3.3 Channel-specific machine data
Parameter Manual
144 List Manual, 01/2017
