This machine data must refer to a valid base frame.
If its content is less than 0 or greater than or equal to the maximum number of base
frames set in
MD28081 $MC_MM_NUM_BASE_FRAMES, selection of a corresponding tool holder
causes an alarm.
20188 TOCARR_FINE_LIM_LIN C07 W1
mm Limit of linear fine offset TCARR DOUBLE Immediately
-
808d-me42 - 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
0.0 - 7/3 M
808d-me62 - 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
0.0 - 7/3 M
808d-te42 - 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
0.0 - 7/3 M
808d-te62 - 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
0.0 - 7/3 M
808d-mte40 - 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
0.0 - 0/0 M
808d-mte60 - 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
0.0 - 0/0 M
Description: Indicates for each channel the input limit for the linear fine offset values of an
orientable tool holder.
20190 TOCARR_FINE_LIM_ROT C07 W1
degrees Limit of rotary fine offset TCARR DOUBLE Immediately
-
808d-me42 - 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
0.0 - 7/3 M
808d-me62 - 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
0.0 - 7/3 M
808d-te42 - 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
0.0 - 7/3 M
808d-te62 - 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
0.0 - 7/3 M
808d-mte40 - 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
0.0 - 0/0 M
808d-mte60 - 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
0.0 - 0/0 M
Description: Indicates for each channel the input limit for the rotary fine offset values of an
orientable tool holder.
20191 IGN_PROG_STATE_ASUP EXP K1
- Do not display interrupt program execution on OPI DWORD NEW CONF
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7FFFFFFF 2/2 M
Description: The execution of the ASUB assigned to the interrupt is NOT displayed by the OPI
variables "progStatus" and "chanStatus".
Bit 0 = 1: Enable interrupt 1 (user interrupt)
Bit 1 = 1: Enable interrupt 2 (user interrupt)
...
Bit 7 = 1: Enable interrupt 8 (user interrupt)
Bit 8 = 1: Enable interrupt 9 (system interrupt, reserved)
Machine data
3.3 Channel-specific machine data
Parameter Manual
146 List Manual, 01/2017
