Siemens SINUMERIK 808D

Description: Number of fixed point positions set, i.e. the number of valid entries in MD30600
$MA_FIX_POINT_POS.
For G75, two (2) fixed point positions are assumed in MD30600 $MA_FIX_POINT_POS for
reasons of compatibility, even if '0' has been entered in this machine data.
31000 ENC_IS_LINEAR A02, A11 G2
- Linear scale BOOLEAN PowerOn
-
- 1 FALSE, FALSE 0 - 2/2 M
Description: MD = 1: Encoder for position actual-value acquisition is linear (linear scale).
MD = 0: Encoder for position actual-value acquisition is rotary.
The index [n] of the machine data has the following coding:
[encoder no.]: 0 or 1
31010 ENC_GRID_POINT_DIST A02, A11 G2
mm Division period for linear scales DOUBLE PowerOn
-
- 1 0.01, 0.01 0.0 - 2/2 M
Description: For linear measuring system only:
The distance between the reference marks on the linear scale must be entered in this
MD.
Index [n] of the machine data has the following coding:
[encoder no.]: 0 or 1
31020 ENC_RESOL A02, A11 G2, R1
- Encoder lines per revolution DWORD PowerOn
-
808d-me42 1 10000, 10000, 10000,
10000, 10000, 10000,
2048, 2048
1 - 2/2 M
808d-me62 1 2048, 2048, 2048,
2048, 2048, 2048,
2048, 2048, 2048,
2048, 2048...
1 - 2/2 M
808d-te42 1 10000, 10000, 10000,
10000, 10000, 10000,
2048, 2048
1 - 2/2 M
808d-te62 1 2048, 2048, 2048,
2048, 2048, 2048,
2048, 2048, 2048,
2048, 2048...
1 - 2/2 M
808d-mte40 1 2048, 2048, 2048,
2048, 2048, 2048,
2048, 2048, 2048,
2048, 2048...
1 - 2/2 M
808d-mte60 1 2048, 2048, 2048,
2048, 2048, 2048,
2048, 2048, 2048,
2048, 2048...
1 - 2/2 M
Description: For rotary measuring system only:
The number of encoder lines per encoder revolution must be entered in this MD.
Index [n] of the machine data has the following coding:
[encoder no.]: 0 or 1
Machine data
3.4 Axis-specific machine data
Parameter Manual
List Manual, 01/2017 235
