Siemens SINUMERIK 808D Parameter Manual

808d-mte40 - 0x00 0 0x7 7/2 M
808d-mte60 - 0x00 0 0x7 7/2 M
Description: Special gantry functions are set with this MD.
The MD is bit-coded, the following bits are assigned:
Bit 0 == 0:
Extended monitoring of the actual value difference is inactive.
An offset between master and slave axes occurring in tracking or BREAK_UP is not taken
into account in the monitoring of the actual value difference.
Alarm 10657 is not output if alarm 10563 occurs before Power OFF.
Bit 0 = 1:
Extended monitoring of the actual value difference is active.
An offset between master and slave axes occurring in tracking or BREAK_UP is taken into
account in the monitoring of the actual value difference.
Prerequisite: The gantry grouping must be rereferenced or resynchronized after control
startup.
Alarm 10657 is output if alarm 10563 occurs before Power OFF.
Bit 1 = 0:
Zero mark search direction of the slave axis analogous to MD 34010
Bit 1 = 1:
Zero mark search direction of the slave axis same as for master axis
Bit 2 = 0 :
Alarm 10655 "Synchronization in progress" is output
Bit 2 = 1
Alarm 10655 "Synchronization in progress" is not output
37500 ESR_REACTION EXP, A01, A10 M3, P2
- Axial mode of "Extended Stop and Retract" BYTE NEW CONF
CTEQ
808d-me42 - 0 0 22 ReadOnly M
808d-me62 - 0 0 22 ReadOnly M
808d-te42 - 0 0 22 ReadOnly M
808d-te62 - 0 0 22 ReadOnly M
808d-mte40 - 0 0 22 7/2 M
808d-mte60 - 0 0 22 7/2 M
Description: Selection of the response to be triggered via system variable "$AN_ESR_TRIGGER".
0 = No response Reaktion (or only external response through synchronized action
programming of rapid digital outputs).
21 = NC-controlled retraction axis
22 = NC-controlled stopping axis
37510 AX_ESR_DELAY_TIME1 EXP, A01, A10 P2
s Delay time ESR single axis DOUBLE NEW CONF
CTEQ
808d-me42 - 0.0 0.0 - ReadOnly M
808d-me62 - 0.0 0.0 - ReadOnly M
808d-te42 - 0.0 0.0 - ReadOnly M
808d-te62 - 0.0 0.0 - ReadOnly M
808d-mte40 - 0.0 0.0 - 7/2 M
808d-mte60 - 0.0 0.0 - 7/2 M
Machine data
3.4 Axis-specific machine data
Parameter Manual
318 List Manual, 01/2017
