Siemens SINUMERIK 808D

42970 TOFF_LIMIT - F2
mm Upper limit of correction value via $AA_TOFF DOUBLE Immediately
-
808d-me42 3 10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0...
0.0 - 0/0 S
808d-me62 3 10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0...
0.0 - 0/0 S
808d-te42 3 10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0...
0.0 - 0/0 S
808d-te62 3 10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0...
0.0 - 0/0 S
808d-mte40 3 10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0...
0.0 - 7/7 U
808d-mte60 3 10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0...
0.0 - 7/7 U
Description: Upper limit of the offset value which can be defined by means of synchronized actions
via the $AA_TOFF system variable.
This limit value influences the absolutely effective amount of offset through $AA_TOFF.
Whether the offset value is within the limit range can be checked via the
$AA_TOFF_LIMIT system variable.
42972 TOFF_LIMIT_MINUS - F2
mm Lower limit of the offset value $AA_TOFF DOUBLE Immediately
-
808d-me42 3 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0,...
- 0.0 0/0 S
808d-me62 3 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0,...
- 0.0 0/0 S
808d-te42 3 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0,...
- 0.0 0/0 S
808d-te62 3 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0,...
- 0.0 0/0 S
808d-mte40 3 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0,...
- 0.0 7/7 U
808d-mte60 3 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0,...
- 0.0 7/7 U
Description: Lower limit of the offset value which can be specified through synchronous actions via
the system variable $AA_TOFF.
This limit value acts on the active correction through $AA_TOFF in the minus direction.
This limit value is only effective if $MC_TOFF_MODE Bit6 = 1 is set.
Über die Systemvariable $AA_TOFF_LIMIT kann abgefragt werden, ob sich der
Korrekturwert im Grenzbereich befindet.
